Metris Cargo Van
Color
Arctic WhiteCargo Van Lineup
2023
Dimensions
- Length:
- 202.4 in
- Width (w/o mirrors):
- 75.9 in
- Width (incl. mirrors):
- 88 in
- Height:
- 75.2 in
- Height with roof rails:
- 77.1 in
- Wheelbase:
- 126 in
- Overhang front/rear:
- 35.2 in/41.1 in
- Cargo Length (without partition):
- 105.4 in
- Cargo Length (with thru-loading partition):
- 111.5 in
- Max. Cargo Width:
- 66.3 in
- Cargo Floor Width (btw. wheelhouse):
- 50 in
- Min. Cargo Height:
- 53.8 in
- Max. Cargo Height:
- 55 in
- Cargo Volume:
- 182.9 cu. ft.
- Ground Clearance:
- 5.4 in
- Side Door Opening Height:
- 49.3 in
- Side Door Opening Width (at floor):
- 37.8 in
- Rear Cargo Door Opening Height:
- 49.6 in
- Rear Cargo Door Opening Width:
- 54.8 in
- Turning Diameter (Wall to Wall):
- 38.7 ft
- Turning Diameter (Curb to Curb):
- 36.4 ft
- Headroom (1st row):
- 39.6 in
- Leg room (1st row):
- 35.8 in
Key Features
- Engine:
- 4-Cylinder Gas
- Payload Capacity:
- 2,205 lbs
- Towing Capacity:
- 5,000 lbs [1]
- Seating Capacity:
- 2
Capacity
- Payload Capacity:
- 2,205 lbs
- Seating Capacity:
- 2
- Cargo Volume:
- 182.9 cu.Ft
- Fuel Tank:
- 18.49 g
- Max Roof Load:
- 331 lbs
- GAWF / GAWR:
- 3,196 lbs
- Towing Capacity:
- 5,000 lbs [1]
- GVWR:
- 6,393 lbs
- GCWR:
- 11,391 lbs
- Base Curb Weight:
- 4,123 lbs
Measurements
Powertrain
- Engine:
- 4-Cylinder Gas
- Horsepower:
- 208 hp @ 5,500 rpm
- Torque:
- 258 lb-ft @ 1,250-4,000 rpm
- Rear Axle Ratio:
- 3.467
- 1st Gear:
- 5.354
- 2nd Gear:
- 3.243
- 3rd Gear:
- 2.252
- 4th Gear:
- 1.636
- 5th Gear:
- 1.211
- 6th Gear:
- 1.000
- 7th Gear:
- 0.865
- Reverse:
- -4.798
- 8th Gear:
- 0.717
- 9th Gear:
- 0.601
2023
Dimensions
- Length:
- 211.4 in
- Width (w/o mirrors):
- 75.9 in
- Width (incl. mirrors):
- 88 in
- Height:
- 75.2 in
- Height with roof rails:
- 77.1 in
- Wheelbase:
- 135 in
- Overhang front/rear:
- 35.2 in/41.1 in
- Cargo Length (without partition):
- 114.5 in
- Cargo Length (with thru-loading partition):
- 120.5 in
- Max. Cargo Width:
- 66.3 in
- Cargo Floor Width (btw. wheelhouse):
- 50 in
- Min. Cargo Height:
- 53.8 in
- Max. Cargo Height:
- 55 in
- Cargo Volume:
- 199.2 cu. ft.
- Ground Clearance:
- 5.2 in
- Side Door Opening Height:
- 49.3 in
- Side Door Opening Width (at floor):
- 37.8 in
- Rear Cargo Door Opening Height:
- 49.6 in
- Rear Cargo Door Opening Width:
- 54.8 in
- Turning Diameter (Wall to Wall):
- 41 ft
- Turning Diameter (Curb to Curb):
- 38.7 ft
- Headroom (1st row):
- 39.6 in
- Leg room (1st row):
- 35.8 in
Key Features
- Engine:
- 4-Cylinder Gas
- Payload Capacity:
- 2,150 lbs
- Towing Capacity:
- 5,000 lbs [1]
- Seating Capacity:
- 2
Capacity
- Payload Capacity:
- 2,150 lbs
- Seating Capacity:
- 2
- Towing Capacity:
- 5,000 lbs [1]
- Cargo Volume:
- 199.2
- Fuel Tank:
- 18.49 g
- Max Roof Load:
- 331 lbs
- GAWF / GAWR:
- 3,196 lbs
- GVWR:
- 6,393 lbs
- GCWR:
- 11,391 lbs
- Base Curb Weight:
- 4,178 lbs
Measurements
Powertrain
- Engine:
- 4-Cylinder Gas
- Horsepower:
- 208 hp @ 5,500 rpm
- Torque:
- 258 lb-ft @ 1,250-4,000 rpm
- Rear Axle Ratio:
- 3.467
- 1st Gear:
- 5.354
- 2nd Gear:
- 3.243
- 3rd Gear:
- 2.252
- 4th Gear:
- 1.636
- 5th Gear:
- 1.211
- 6th Gear:
- 1.000
- 7th Gear:
- 0.865
- Reverse:
- -4.798
- 8th Gear:
- 0.717
- 9th Gear:
- 0.601
